Pilot Operated Wafer PRV

Pilot Operated Wafer PRV (KRWP)

Product Code: KRWP
The KRWP automatically reduces pressure from a higher inlet pressure to a steady lower outlet pressure by using an accurate control pilot that responds to changes in the water supply pressure. When downstream pressure exceeds the pressure setting of the control pilot, the KRWP closes.

Basic Applications:

The KRWP is a pilot operated pressure reducing valve designed to be used in various places. Use the KRWP where large flow and space saving is required such as with water distribution pipes in industrial plants or municipal water supply systems.

Features:

  • Completely Automatic
  • New Wafer Design Cuts Weight by 50%
  • Installation Time Cut in Half
  • Bronze Material Prevents Rust Contamination
  • Stainless Steel Materials Ensure Water Purity
  • Simple Installation and Maintenance
  • Operates Vertically or Horizontally

Specifications:

Nominal Sizes: 65mm (2½"), 80mm (3"), 100mm (4"), 125mm (5"), 150mm (6"), 200mm (8")
Working Temperature: 0 to 80°C
Applicable Fluid: Water
Working Pressure (inlet): above 0 to 1.6 MPa
Standard Set Pressure: 200kPa
Shell Test Pressure: 2.4 MPa
Set Pressure Outlet
Choice of Spring:
100~350kPa
350~550kPa
550~750kPa
750kPa~1200kPa
